Model: YJ-2S-03

Automatic Shaker

The shaker YJ-2S-03 only need few steps necessary to start working, which is extremely appreciated by the operators. It is able to select the correct parameters to optimize clamping force, shaking time for you.

While operating, the shaker surprises for its silence, the design of the frame contribute to absorbing the bothering noises .

SEND INQUIRY

Features

Parameter

PRODUCT DETAIL

DOCUMENTS Download

IT GOES WELL WITH

Features

Satisfied mixing effect

Automatic clamping
Low noise during shaking
Fastly and thoroughly mix by high speed vibration

Friendly Operation

Optional shaking time between 1 - 9 mins.
AAdjustable clamping force for different sizes of can.
Chinese and English user interface for option.
The LCD display is easier to read for the operator and clearly shows each phase of the shaking process.
Simple electrical structure, easy to maintain
Wheels and feet at bottom, convenient to move the shaker.

Safty

Safety inspection switch for door , the shaker will stop running when the door is open.
Shaking structure separate with the case, will not affect the case when high speed shaking.
Centrifugal switch and overheating protection for shaking motor, effective to extend the motor life.

PARAMETERS

BASE FEATURES**
Type	Vibrational shaker
Clamping function	Automatic
Clamping force	Adjustable
Shaking time	1 to 120 minutes
Shaking speed	Up to 710 shakes per minute
CAN SPECS**
Type of cans	Round / Square / Oval
Suitable can height	50-400mm
Maximum can diameter	350mm
Multiple can handling	Yes (The can must be the same height)
Maximun weight	35 KG
POWER SUPPLY / MACHINE ENVIRONMENT**
Power supply -- Frequency	Single phase 110 /220 V ±10% -- 50/60 HZ
Rated power	750 W
DIMENSIONS **
Machine Size	720 (L) X 710(W) X 1045(H) MM
Packing Size	760 (L) X 740(W) X 1160(H) MM
Footprint	0,51 ㎡
WEIGHT **
Machine Weight	206 KG
Gross Weight	224 KG
LOADING QUANTITY **	42 sets / 20" Container
PACKING **	Carton
CERTIFICATE**	CE

PRODUCT DETAIL


control panel	The movement is separated from the chassis for smooth operation.	Electronic board with high technology.


Simple electrical mechanism for easy maintenance.	Electromagnetic door lock, secure

PACKING
